Fluent Modeling Environment

IRONCAD has always delivered a clean and simple approach to design allowing engineers to really think in 3D and create models dynamically on screen without having to pre-plan and map out the concept in advance. IRONCAD’s seamlessly integrated design tools are intuitive and user friendly.

Design The Way You Want
The combination of IRONCAD’s Innovative design environment with the more conventional history-based structured design environment, allows users to choose, at an individual part level, which process is most appropriate for the particular part they are designing:

Innovative Design
Delivers real flexibility, allowing users to directly manipulate the parts independent of history and constraints while maintaining feature design information. Essential for conceptual modeling.

Structured Design
Allows users to build rigid feature dependent parts with embedded design intent, delivering more control over future changes.

Familiar Detailing Environment

IRONCAD NextGeneration incorporates a powerful 2D design environment offering one of the most powerful annotation tools on the market today, embedded as a standard drafting environment and/or as an integrated 3D detailer. In addition to its familiar user friendly
interface, IRONCAD’s new 2D environment offers all the functionality users have come to expect from some of the market leading standalone 2D design tools.
Communicate Data Effectively

Creating data is only half the story. IRONCAD Next Generation delivers the tools to get this information out to customers, manufacturing, and suppliers clearly and effectively:

Model Data Exchange
With both ACIS and Parasolids kernels, and a range of native translators, IRONCAD can export model data in ALL industry standard formats.

Customer Communication
IRONCAD delivers a range of tools to allow you to keep your customers closely involved in your projects by including photo-realistic rendering, 3D/2D PDF, web publishing of models, and a standalone 3D viewer all standard in the core product.

Being able to communicate is good, but sharing live project data requires control and management. IRONCAD's Next Generation suite includes, CAXA EDM a powerful and integrated fully functional EDM solution to manage your CAD and related engineering project data, both internally and externally across the world wide web.

Design Validation

The ability to stringently test design data, allows users to reduce unnecessary prototypes and ultimately cost from a project. In today’s economic climate, this is more critical than ever before. IronCAD has teamed up with a leading Finite Element Analysis specialist to deliver powerful FEA functionality, operating from within Next Generation.

“Now that the power is available to you,
what will you do with it?”
